SMSW 24 -ASTR

0 Puan - 0 Yorum
Stok Kodu
SMSW 24 -ASTR
Stok Durumu
Stokta Yok

Spherical washers are designed to create an exact, parallel plane between the bolt head and the face of the nut. These washers automatically adjust and compensate for the angular deviation between the planes and prevent the bolt from bending.

Faydalar

  • ✔ Automatically compensates for angular errors
  • ✔ Evenly distributed bolt tension
  • ✔ Reduces bolt fatigue from bending bolts
  • ✔ Improved bolt stretch possible due to increased clamping length
  • ✔ Surface treated for protection in humid and harsh environments
  • ✔ Available in standard and low-profile (LP) versions
Boyutlar
Delik çapı27mm
Dış çap47mm
Yükseklik60mm
Lojistik
Ürün net ağırlığı0.407kg
eClass kodu23-05-20-01
UNSPSC kodu20122410
Özellikler
MalzemeAlloy Steel. surface treated
TreatmentNitrokarbürize
UygulamaMachinery installed on SKF Vibracons
